Lucid Scribe 1.4.4

Replaced an obscure error message with a note that Windows Media player is required, added a “Maximize Values” option to the context menu of the minute view along with a “Split Stages” option to split stage data into Awake, REM, Light, Deep and Sleep, and flipped the icons for plug-outs.

Stages

Download now

Originally posted on Lucid Dream Art:

The latest Lucid Scribe plugin for use with the Wild Divine Lightstone is now available thanks to Michael.

This will give my project more flexibility due to the lower threshold now offered, without having to modify the hardware or increase the LED light output to otherwise gain the extra reflected sensitivity.

 Lucid Scribe screenshot of waking closed eye-movement via the new plugin

Screenshot of Lucid Scribe showing waking closed eye-movement via the new plugin

This doesn’t make the previous version of the plugin redundant however.

On the contrary, this now gives me the extra option of tailoring the sensor design further should I wish to, including the idea of maybe swapping the photoresistor for a suitable photodiode instead.

The latest Lightstone IOM v0.9.9 plugin is now available from Lucidcode here.

View original

Made sure it doesn’t turn itself back on again a minute after turning itself off.

Download now | View code changes

Lowered the threshold on the IR LED REM channel from 196 down to 156.

Download now

Originally posted on Lucid Dream Art:

This follows on from my previous post about the Wild Divine Lightstone where I have included more detail about the sensors themselves in relation to my DreamJacker mask project.

Photosensor mounted in mask

Lightstone photo sensor mounted in mask

I have now also utilised a suitable IR led from an old remote control to act as the transmitter in order to reflect the light off my closed eyelid and back on to the photoresistor. This signal is then fed to the Lightstone interface which acts as an analogue to digital converter with hardware connection to my computer via a short usb cable.

Lucidcode do already have a suitable plugin to monitor the heartbeat and GSR (Galvanic Skin Response) by using the standard finger electrodes originally supplied with the Lightstone, including software intended for the later IOM versions.

Lucid Scribe heart trace screenshot using Lightstone electrodes

Lucid Scribe screenshot showing heartbeat via Lightstone electrodes

However Michael kindly updated the plugin by adding the…

View original 29 more words

Added code to turn off after 60 seconds.

Download now | View code changes

Mouse FIELD 1.1.2

Added a new channel: Button TCMP, which interprets Morse Code patterns from mouse clicks and forwards them to the keyboard input. A quick click is a dot and anything longer is a dash. It is disabled by default so it needs to be enabled under plugins.

Download now | View code changes | LSDBase entries

Zeo 1.0.1

Fixed the sleep stage value again. It now definitely triggers during REM!

Download now | View code changes | LSDBase Entries

Lucid Scribe 1.4.3

Added a time column for single-hour CSV exports.

Download now

OCZ hack

Originally posted on Lucid Dream Art:

This makes use of the OCZ NIA (Neural Impulse Activator) advanced biotechnology games interface as an analogue to digital converter, by replacing the headband and just stuffing a small analogue signal in one of the inputs in relation to the reference (centre) connector pin.

OCZ NIA headband and interface

This contemplated my DIY motion sensor project where only the RX diode signal is used.

Read more about OCZ NIA hack.

View original
